Made for roads and city. Point A to point B just got a whole lot sweeter. Experience the wind in your face, air in your lungs, and what life on two wheels has to offer. Enhance your everyday adventure with the new CrossCore RC. Charge. Pedal. GO!

Suggested Use - Casual Pavement Adventure

Request More Information Print Brochure
Calculate Payment
Compare Models Insurance Quote

2024 Yamaha CrossCore RC - Large

Condition
New
Category
Electric Bicycles
Model Type
Fitness / Lifestyle
Model Code
CCORRCLSAG
Color
Urban Sage

Features

  • PWSERIESST: With pedal assist power up to 28mph, Yamaha's Quad Sensor System delivers assist in all conditions and offers a broad range of power assist modes that work great for many different styles of riding.
  • HYDRAULIC DISC BRAKES: Hydraulic disc brakes and center lock rotors provide you with strong, dependable braking power in all conditions. Power when you want it, braking when you need it.
  • LARGE VOLUME ROAD AND CITY TIRES: Large volume 2” wide tires means smoother pedaling over rough surfaces for a more comfortable ride feel. Now you can comfortably stay out longer or go even further.
  • YAMAHA 500WH BATTERY: Yamaha’s proven 500 Watt-hour Lithium-ion battery encased inside the frame provides you with great function, reliability, and protection. When it’s time to plug-in the high-speed charger, you can choose to recharge with the battery pack in the frame or take it out for convenient storage.
  • INTEGRATED SPEED SENSOR: Engineered into the rear hub and an exclusive design to Yamaha bicycles, our speed sensor immediately recognizes the slightest change in rolling speed and adjusts motor input to deliver a smooth and natural power assist feel.
  • COMFORT FOCUSED SUSPENSION: Bring the smooth and easy-to-adjust comfort of the SR SuntourNEX fork. Take the thud out of small bumps and rough roads with 2.5” of cushion without losing the quick handling characteristics of the optimized frame geometry.
  • MODES, DISPLAY, AND SWITCH: Utilizing our Quad Sensor System, the NEW Automatic Mode brings an added peace of mind to our 4-mode system for smooth and powerful assist. Our new display is designed for a wide range of uses, from city to trail riding and features a simple and easy to operate LCD display with speed and battery capacity functions.

General Information

Manufacturer
Yamaha
Model Year
2024
Model
CrossCore RC - Large
Model Code
CCORRCLSAG
Color
Urban Sage

Brakes / Wheels / Tires

Brakes
Hydraulic disc brake. 2-finger lever
Brake Rotors

Shimano SM RT21

Front - 7.1 in. (180 mm)

Rear - 6.3 in. (160 mm)

Rims
275 in. 32-hole dual channel welded pin with eyeleted spoke
Spokes
SUS304 14G
Spoke Nipples
Brass
Front Hub
0.5 x 3.9 in. (12 x 100 mm) Quick-Release Thru-Axle (QRTA)
Rear Hub
0.5 x 5.6 in. (12 x 142 mm) QRTA with integrated speed sensor
Tires
CST C1996 27.5 x 2.0 in.

Dimensions

Length

Top tube - 23.6 in. (599 mm)

Reach - 15.4 in. (390 mm)

Head tube - 5.5 in. (140 mm)

Seat tube - 21.7 in. (552 mm)

Height

Stack - 24.6 in. (626 mm)

Stand over - 33.3 in. (847 mm)

Wheelbase
42.9 in. (1,090 mm)
Weight
Total - 52.6 lb.
Frame Size
23.6 in. (600 mm)

Drive

Shifters

Shimano M2010 9-speed

Gear selection window

Front Derailleur
Shimano Sora (2 x 9) braze-on
Rear Derailleur
Shimano M3100 SGS
Crank Arm

Square taper

Length - 6.7 in. (170 mm)

Chain
KMC e11 118 links
Cassette

Shimano HG400 9-speed

11-13-15-17-20-23-26-30-36T

Chainrings
Samox 44t

Electrical

Motor

PWSeries ST, 3-bolt mount, square taper spindle, quad sensor system with rear hub speed sensor

Weight - 7.71 lb.

Battery

Yamaha 500Wh lithium ion with charge-life indicator and self-diagnosis display

Side-exiting dock station with anti-vibration mounting plate

Battery Weight
6.61 lb.
Max Cadence support
110 rpm
Advanced Electronics
Computer control functions include - (4) Power-level control switch, stopwatch, distance units, power-level LED on/off, cycling function display items, time adjustment, LED headlamp power on/off, 3-color LED power assist level light indicator
Watts
Rated power - 250 W (nominal), 500 W (max)
Volts
36 V
Max Torque
70 Nm
Power Modes
Support modes - AUTO, ECO+, ECO, STANDARD, HIGH
Display
Cycling function display includes - Speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%)
Charge Time
4-hours

Frame

Frame

Yamaha hydroformed aluminum

Integrated battery

Water bottle boss

Tapered headtube

Internal shift / brake hose routing

Rack / fender compatible

Fork

SR Suntour NEX E25

Travel - 2.5 in. (63 mm)

0.07 x 3.9 in. (2 x 100 mm) thru-axle

Headset
Integrated headset with 1.2 in. (30 mm) spacers
Stem

Yamaha Alloy 4-bolt faceplate

Diameter - 1.3 in. (31.8 mm)

Length - 3.9 in. (100 mm)

Handlebar

Alloy flat bar zero degree rise

Diameter - 1.3 in. (31.8 mm)

Width - 25.2 in. (640 mm)

Grips
Two-tone ergonomic locking
Seatpost

Alloy 1.2 x 13.6 in. (30.9 x 345 mm) with 2-bolt adjustable tilt saddle rail clamp

Collar - Alloy 2-bolt 1.4 in. (35 mm)

Length - 13.6 in. (345 mm)

Saddle
Yamaha Urban Comfort Cro-Mo Rail

Operational

Max. Speed
Support - 28 mph
Suggested Use
Casual Pavement Adventure

Other

Additional colors

Painted Desert

Shiver White

Urban Sage

Includes

BB drop - 2.5 in. (63 mm)

Rear center - 18.3 in. (465 mm)

Head tube angle - 71.1°

Seat tube angle - 71.6°

Warranty
5-year on frame, drive unit, battery
